Corken’s CP-model pumps are ideal for petroleum products with low vapor pressures such as petroleum based oils, fuel oils, lube oils and thin liquids such as alcohols and solvents. These pumps utilize gasket and O-ring construction and feature a adjustable internal relief valve. Multiple mechanical sealing options are available.

Flow rates up to 400 gpm (1,514 l/min)
Working pressures up to 200 psi (13.8 bar)
Differential pressures up to 125 psi (8.6 bar)
Temperature range: -25 to 225 °F (-32 to 107 °C)
Viscosities up to 20,000 SSU (4,250 cSt)

• Multiple pump sizes
• Designed for high pressure applications with a maximum working pressure of 400 psi (28.6 bar)
• Foot mounted design
• Double extended shaft only
• O-ring construction
• Six vane design (number of vane drivers varies by model)
• Mechanically sealed with silicon carbide seal seat
• Gear reducer and V-belt drive options only
• Available with NPT connections only

• Pump casing and heads: Gray iron or ductile iron
• Cam and sideplates: Gray iron
• Rotor and flanges: Ductile iron
• Seal seat: Silicon carbide
• O-rings: Buna-N, PTFE, Viton®, Neoprene®.
• Blades: Advanced polymers

• Self-adjusting sliding vanes maximizes performance.
• Cam and sideplates can be replaced. Sideplates are reversible.
• Maintenance is simple and cost effective: By simply removing the pump head, you can easily replace the internals without disturbing the piping.
• Can handle small amounts of vapor so they are ideal for liquefied gases.
• Excellent suction lift is great for clearing suction and discharge lines.
• Adjustable internal relief valve.

• Aviation fuels
• Fuel oils
• Liquefied gases
• Lube oils
• Solvents
• And many more

• Terminal
• Bulk plant
• Truck and transport
• Mobile (trailers & portable skid units)

• Chemical and petrochemical process
• Oil and natural gas production
• Alternative fuels
• Refined petroleum products
• Truck and transport
• Liquid terminals
• Marine
