Double diaphragm air-operated pumps for dosing, spraying, transferring, and spreading a wide range of fluids in applications with modest flow rates. Pump wetted parts are appropriate for use in corrosive situations and are compatible with even the most hostile fluids. Polypropylene is used to construct the air motor's directional air valve and air chamber covers.
Certification |
- |
Wetted materials |
Polypropylene, Stainless steel, Stainless steel (AISI 316), Hytrel, PTFE |
Maximum dry suction head |
4 m (13 ft) |
Fluids |
Aceite, Water, Non aggressive chemicals |
Air inlet |
3/8" NPSM (F) |
Weight |
1.9 kg (4.19 lb) |
Maximum wet suction head |
8 m (26 ft) |
Maximum free flow delivery |
38 l/min (10 gal/min) |
Pressure ratio |
1:1 |
Fluid outlet |
1/2" BSPP (F) |
Fluid inlet |
1/2" BSPP (F) |
Pump size |
1/2" |
Solids in suspension maximum size |
3 mm (0.12 ") |
Delivery per cycle |
0.14 l (0.04 gal) |
Air pressure operating range |
1.5 - 8 bar (20 - 120 psi) |
Product code |
Diaphragms |
Balls |
Seats |
Other wetted materials |
Air motor |
Fluid Path |
DF30PPSESTMBAS |
Santoprene |
PTFE |
Stainless steel (AISI 316) |
Stainless steel |
Polypropylene |
Polypropylene |
DF30PDSTSTTBAS |
PTFE |
PTFE |
Stainless steel (AISI 316) |
Stainless steel |
Polypropylene |
Conductive acetal |
DF30PPSTSTTBAS |
PTFE |
PTFE |
Stainless steel (AISI 316) |
Stainless steel |
Polypropylene |
Polypropylene |
DF30PKYTWTTBAS |
PTFE |
PTFE |
PVDF |
Hastelloy C |
Polypropylene |
Conductive PVDF |
DF30PPYTWTTBAS |
PTFE |
PTFE |
PVDF |
Hastelloy C |
Polypropylene |
Polypropylene |
DF30PPSVSTHBAS |
Hytrel |
PTFE |
Stainless steel (AISI 316) |
Stainless steel |
Polypropylene |
Polypropylene |
